Buffalo Aluminium Bubble Insulation Foil
PRODUCT DESCRIPTION
3 layers aluminum foil heat insulation wrap consists of pure aluminum film bonded to a layer of bubbles, Buffalo FOIL is a high cost performance choice for heat insulation. The foil will be installed before any roofing product installation, and the aluminium reflective foil layers can blocks 97% of radiation heat. The average temperature that bubble foil can reduce is around 6 degree Celsius.
SPECIFICATIONS
| Physical Properties | |||
|---|---|---|---|
| No | Properties | Test Method | Result |
| 1 | Thickness | - | 5mm |
| 2 | Weight | - | 370 G/M2 |
| 3 | Roll Size | - | 1.2 x 30m |
| 4 | Emissivity | ASTM E408 | 0.04 COEF |
| 5 | Reflectivity | ASTM E408 | 96% |
| 6 | Thermal Resistance | - | 3.0m2 0C/W |
| 7 | Sound Reduction | ASTM E384 | 55% |
| 8 | Water Vapour Transmission | ASTM E96-2000 | 0.014G/M2 KPA |
| 9 | Fire Rate | IS755 | Class II |
| 10 | Fungal Resistance | ASTM C1338 | No Growth |
| 11 | Corrosion | No Corrosion | |
| 12 | Tensile Strength | GB/96-04-10 | 2.95(MD), 2.75(TD) |
| 13 | Elongation Rate | GB/96-04-10 | 19%(MD), 13.5%(TD) |
| 14 | Tear Strength | ASTM D882 | 16.5N(MD), 14.5N(TD) |
PRODUCT APPLICATION
- To laminate or coat EPE,XPE,IXPE,Kraft as good building / construction thermal insulation material to reduce heat.
- roof, attic, underlay and floor insulation under concrete and wood
- crawl space, stud wall, metal frame building insulation
- Wrapping
- protective coating of ventilating pipe, HVAC duct and pipe
- shells of air conditioner and water heater
- wrap house & pipe
- industrial & commercial sheds
